SmartBoard
2
Introduction
9
The SmartBoard is designed to be mounted on the outside of the vehicle frame
with a connection to Trailer EBS D or E.
2.1 SmartBoard for ADR (GGVS) vehicles
WABCO have developed a new SmartBoard version that allows trailers that carry
dangerous goods to take advantage of SmartBoard functions. A SmartBoard suit-
able for GGVS vehicles is available under the product number 446 192 111 0.
Operation of the SmartBoard is identical to the standard version. Some functions
are restricted, however, due to the operation without a battery:
• No date and time function is available. For this reason it is not possible to store
messages.
• The odometer reading of the Trailer EBS is displayed. The internal odometer is
without function.
• Information is displayed when the trailer is supplied with power.
SmartBoard
446 192 110 0
SmartBoard for ADR vehicles
446 192 111 0
Table: 2-1: SmartBoard versions
The fitting dimensions and cable connections are unchanged. The SmartBoard is
installed in compliance with the approval certificate TUEH - TB 2007 - 132.00. The
certificate can be obtained from the product catalogue INFORM on the Internet at
www.wabco-auto.com by entering the product number or the index words “Smart-
Board“ or “certificate“.
