SmartBoard
4
Operation and Functions
39
4.6 Extended settings
4.6.1 Start Screen (Splash Image)
The SmartBoard Diagnostic Software can be used to load one picture into the
SmartBoard. This image is then displayed for one second when the software is
started.
A start screen template and a WABCO suggestion for editing the file is available for
download at: www.wabco-auto.com <Service & Support> <Download-Center>
<SmartBoard Splash Image Example>.
This file can be modified using suitable software. It is also possible to create your
own start screen. The file must have the following properties:
File properties Values
File format: *.BMP (BMP = Bitmap)
Image size: 128 × 64 pixels
Shading depth: 2 bit (black / white)
Table: 4-4: Start screen properties
4.6.2 Configuration of the main menu
During start-up procedures for the SmartBoard and each time the menu item
<Tools> <Auto Config> is called up, the main menu is adapted for the installed
components (see chapter 3.2 "System prerequisites", page 11).
• Any new components that the SmartBoard detects are immediately added to
the display configuration.
• If a component is no longer available, the last valid status is displayed - the
component is not automatically hidden.
The "Air Suspension" component is an exception in this regard because it is no
longer available with the ignition OFF.
If the lining wear indicator (BVA) or the tyre monitoring system (IVTM) is removed
from the overall system, it is necessary to initiate an automatic configuration. The
menu item <Tools> <Auto Config> must be used for this purpose (see chap-
ter 4.4.14.4 "Auto Config", page 36).
