SmartBoard
Table of Contents
4
1 Important instructions and safety instructions 6
1.1 Measures for avoiding electro-static charge and uncontrolled discharging (ESD) 7
2 Introduction 8
2.1 SmartBoard for ADR (GGVS) vehicles 9
3 System Description 10
3.1 System configuration 10
3.2 System prerequisites 11
4 Operation and Functions 14
4.1 Switching On / Off 14
4.2 Key assignment 15
4.3 Menu Structure 15
4.4 Functions 17
4.4.1 Odometer Status 17
4.4.2 Immobilizer 18
4.4.3 Brake lining wear indication (BVA) 20
4.4.4 Axle load indication 20
4.4.5 Tyre-pressure monitoring 21
4.4.6 Information 21
4.4.7 Air suspension 22
4.4.8 Relaxation function 25
4.4.9 Brake release function 26
4.4.10 Road Finisher Brake 26
4.4.11 Vehicle inclination 27
4.4.12 GIO function 27
4.4.13 Language 28
4.4.14 Tools 29
4.5 Output of messages 37
4.6 Extended settings 39
4.6.1 Start Screen (Splash Image) 39
4.6.2 Configuration of the main menu 39
5 Assembly and installation 40
5.1 Cabling Instructions 40
5.2 Start-up 42
6 Diagnosis 43
6.1 Diagnostic Connection 43
6.2 Hardware 44
6.3 Diagnostic Software 44
6.4 Diagnostic Software “SmartBoard” 45
6.4.1 Parameter setting 45
