4
SmartBoard
Operation and Functions
36
If all lift axle(s) are lowered, the calibration is continued.
– Select menu point <Front axle>.
– Select menu point <Calibrate unladen> and enter the weight of the front axle of
the unladen drawbar-trailer.
Button <Arrow right>: Changes the digit position
Button <OK>: Changing the value
Button <Back>: Confirmation of input
– Confirm saving the entered calibration data by pressing the <OK> button.
A successful calibration is indicated with the symbol and checkmark.
– Repeat the last two steps for calibrating the front axle for the partially laden (op-
tional) and for the fully laden drawbar trailer.
Select the respective menu points <Calibrate part. laden> and <Calibrate fully
laden> for this however..
– Repeat steps 4 to 7 for calibrating the rear axle(s) of the drawbar trailer.
Select the respective menu point <Rear axle(s)> for this.
IVTM
This function serves to change the ID of the IVTM wheel modules e. g. after replac-
ing the wheel module) and to change the nominal tyre pressure for each axle.
The <Arrow right> button is used to select the option "Wheel module ID" or "Nomi-
nal pressure" and the selection is confirmed with the <OK> button.
Information Description Note
wheel module ID Changing the
IVTM wheel mod-
ule ID.
Nominal pressure Changing the
nominal tyre pres-
sure (for an axle).
The <Arrow right> button is used to
select the wheel module and the axle
and the <OK> button to confirm.
The <Arrow right> button is used to
select the digit position and the <OK>
button to change the value.
The <Back> button is used to end input
and the <OK> button to save the
changes.
New PIN
This function serves in changing the personal PIN code for operation of the immo-
bilizer (see page 18).
Information Description Note
with old PIN Change the PIN
with PUK Initial immobilizer
activation
Entering and
changing the PIN
with PUK
Button <Arrow right>: Jump to the next
digit position.
Button <OK>: Selecting numbers 0 ... 9
Button <Back>: Confirmation of entry.
4.4.14.4 Auto Config
WARNING
Risk of injury due to lowering of the lifting axles.
– Make sure that no persons are in the trailer danger zone when actuating the
function!
