WAGNER EPG S2 Translation Of The Original Operating Manual

16
EPG S2
OPERATING MANUAL
VERSION 09/2017 ORDER NUMBER DOC2317574
Dimensions:
Height 136 mm; 5.35 inches
Width 270 mm; 10.63 inches
Depth (without operating elements) 300 mm; 11.81 inches
Weight 5.5 kg; 12.13 lb
Electrical:
Mains (AC) 90 VAC–250 VAC
Frequency 47 Hz–63 Hz
AC input power maximum 60 W
Output voltage to guns 2x maximum 22 Vpp
Output current 2x maximum 0.9 A
High voltage 2x 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 μA - 120 μA (adjustable in 1 μA steps)
Tribo current measurement 0 μA - 20 μA (resolution 0.1 μA)
Minimum Tribo current limit 0 μA - 5 μA (adjustable in 0.1 μA steps)
Maximum Tribo current cut o greater than 12 μA
(ATEX: switching o of the unit)
CAN bus IN/OUT Signal optically separated
Protocol: CANopen
Release 24 V DC
Protection class IP 64
Ex zone II 3(2)D 80 °C; 176 °F
Pneumatic:
Input air pressure 0.6–0.8 MPa; 6–8 bar; 87–116 psi
Air  ow maximum 30 m³/h
6 x air quantity regulator with
ACTUAL value measurement
0.00 - 6.00 m³/h
(adjustable in 0.025 m³/h steps)
Required compressed air quality as per
ISO8573.1
6.5.2 (5 μm/+7 °C; +44.6 °F/0.1 mg/m³)
Connection hose diameter 8 mm; 0.315 inches
Ambient conditions:
Operating temperature range +5 °C up to +45 °C; +41 °F up to +113 °F
5.2 TECHNICAL DATA
