WAGNER EPG S2 Translation Of The Original Operating Manual

21
EPG S2
OPERATING MANUAL
VERSION 09/2017 ORDER NUMBER DOC2317574
6 Gun connection B
– To connect a Corona or Tribo gun
7 Gun connection A
– To connect a Corona or Tribo gun
8 Fixations
– For screwing to the rack
9 Cover of the service connection
– Once the cover has been removed, the DIP switches and rotary switches for the
CAN bus address, CAN bus baud rate and the switch for emergency mode can be set.
10 Air outlet for atomizing air gun A
11 Air outlet for dosing air gun A
12 Air outlet for feed air gun A
13 Air outlet for atomizing air gun B
14 Air outlet for dosing air gun B
15 Air outlet for feed air gun B
16 Mains input terminal
– Universal input 90 - 250 VAC
17 Mains output terminal
– To loop the mains through the system
