Operating manual Manual system SPRINT 2
5 Description
Order number 2467031 | Edition 04/2024 19
5.2 EXTENT OF DELIVERY
5.2.1 Variants
Order no. Designation
2465744 Sprint 2 B manual system, standard version
2465745 Sprint 2 H manual system, standard version
2466208 Sprint 2 B manual system, US version
2466209 Sprint 2 H manual system, US version
2466210 Sprint 2 B manual system, Japan
5.2.2 Standard equipment
Stk Order no. Designation
1 See chapter Spare parts list for
Sprint 2 B manual system
[854]
Sprint 2 B manual system
1 See chapter Spare parts list for
Sprint 2 H manual system
[855]
Sprint 2 H manual system without tank
The standard equipment includes:
See chapter Declaration of con-
formity [860]
Declaration of conformity
2467030 Operating manual, in German
See chapter Languages [86] Operating manual in local language
5.3 TECHNICAL DATA
Dimensions:
Height 1150mm; 45.28inch
Width 495mm; 19.49inch
Depth (without operating elements) 740mm; 29.13inch
Weight approx. 40kg; 88.18lbs
Maximum box size 420 x 420 x 400mm; 16.54 x 16.54 x
15.75inches
Maximum filling weight of box 30kg; 66.14lbs
Electrical:
For electrical data, see operating manual for WACON Sprint 2 control unit.
Pneumatic:
Compressed air connection G1/4"
Connection hose diameter 18.5 x 12.5mm
Input air pressure 0.6–0.8 MPa; 6–8 bar; 87–116 psi
Air flow maximum 15m
3
/h; 529.63cf/h
Sum of dosing and feed air 1–6 m
3
/h; 35.3–211.9 cf/h
