Operating manual Manual system SPRINT 2
6 Assembly and commissioning
Order number 2467031 | Edition 04/2024 35
6.5.1 Grounding the powder coating system
P_06025
1
2
4
7
8
6
5
3
1 Only use mains cables with grounding strand!
2 Connect the mobile base's grounding cable to the grounding connection of the
control unit!
3 Connect the control unit's grounding cable with the signal ground!
4 Connect grounding cable to an uncoated metal part of the booth!
5 Remove all paint from hooks and other hanger parts!
6 Wear electrostatically conductive gloves!
7 Wear electrostatically conductive footwear!
8 The floor must be electrostatically conductive!
6.6 SAFETY CHECKS
A skilled person must check to ensure that the device is in a reliable state after it is
assembled and commissioned. This includes:
4
Carry out safety checks in accordance with chapter Safety checks [845].
