WAGNER SPRINT 2 - Tank Version

Operating manual Manual system SPRINT 2
7 Operation
42 Order number 2467031 | Edition 04/2024
7.6.2 60 L tank version
7.6.2.1 Cleaning process when using a single powder tank
Info
For a paint change, all components of the powder feed system must be thoroughly cleaned.
1. Perform cleaning in accordance with chapter Interrupting the coating process of Sprint 2 H
(60 L tank) [841].
2. Open the powder tank and clean all powder feeding parts such as: the spray gun, the
powder
injector, the powder feed hose and the suction system.
3. Clean the powder tank and pay special attention to the fluid base.
Info
Proper fluidization is not possible with a damaged and/or clogged fluid base.
If programs are to be adapted to the new application, proceed as described in the operating manual of
the WACON Sprint 2 control unit.
7.6.2.2 Cleaning process when using multiple powder tanks
Info
For a paint change, all components of the powder feed system must be thoroughly cleaned.
1. Perform cleaning in accordance with chapter Interrupting the coating process of Sprint 2 H
(60 L tank) [841]
2. Pull the powder injector off of the powder tank.
3. Press the catches together at the corrugated surfaces and pull the hose connection part off
the injector housing.
4. Thoroughly blow out the hoses and the injector.
5. Loosen the grounding cable from the powder tank.
6. Replace the powder tank.
7. Reassemble the injector and attach it to the new powder tank.
8. Ground the powder tank by connecting it to the grounding cable.
Info
Proper fluidization is not possible with a damaged and/or clogged fluid base.
7.6.2.3 Restarting the manual system
1. Check if the control unit is switched off.
2. Open the powder tank.
