Pneumatic:
Gun air 0.05–4.0 m
3
/h; 1.7–141.3 cf/h
WAGNER injector type Quick-Link injector
Required compressed air quality as per
ISO8573.1
6.5.2 according to ISO 8573.1, 2010
WARNING
Exhaust air containing oil!
Risk of poisoning if inhaled.
4 Provide compressed air free from oil and water.
Ambient conditions:
When using low-melting powder varieties, an ambient temperature below 30°C (86°F) may
be necessary.
Volume measures:
for volumes specified in Nm
3
(standard cubic meters). One cubic meter of gas at 0°C and
1.013bar is referred to as a normal cubic meter.
The volume flow (air volume) is specified in m
3
/h. The calibration of the WAGNER volume
flow sensor was performed at room temperature with a reference measuring instrument,
that displays the volume flow in Nm
3
/h.
Advertisements:
High voltage 0–100 kV resolution 10 kV
Corona current 0–120 µA resolution 5–20 µA
Tribo current 0–5 µA resolution 0.5 µA
Recipes 50 preset
Switch over from Tribo to Corona Automatic
Connectable spray gun types
WAGNER guns: PEM-X1, PEM-T3
Ambient conditions:
Operating temperature range 5–40 °C; 41–104 °F
Noise development < 63dB (mains pressure 0.6MPa ; 6bar;
87psi)
5.4 OPERATING ELEMENTS
5.4.1 Operating elements on front side
The operating elements on the front side of the control unit are described in the operating
manual of the WACON Sprint 2 control unit.
