Operating manual Manual system SPRINT 2
2 Using in accordance with the instructions
Order number 2467031 | Edition 04/2024 9
2 USING IN ACCORDANCE WITH THE INSTRUCTIONS
2.1 DEVICE TYPE
Manual system for manual coating of grounded work pieces.
2.2 TYPE OF USE
The Sprint 2 manual system is designed for single and serial coatings for industry and
commerce.
The Sprint 2 manual system is comprised of a mobile base, WACON Sprint 2 control unit and
PEM-X1 manual gun.
WAGNER explicitly prohibits any other use!
Electrostatic manual coating systems may only be used in spray areas equipped in
accordance with EN16985:2018 or under equivalent ventilation conditions.
The components of the different versions of the Sprint 2 manual system (Box version),
hopper version (60 L tank) are mutually compatible.
The device may only be operated under the following conditions:
4 Use the device only to work with the materials recommended by WAGNER.
4 Only operate the device as a whole.
4 Do not deactivate safety fixtures.
4 Use only WAGNER original spare parts and accessories.
4 The operating personnel must be trained on the basis of this operating manual.
4 Follow the instructions in the operating manual.
2.3 FOR USE IN POTENTIALLY EXPLOSIVE AREAS
As defined in Directive 2014/34/EU(ATEX), the device is suitable for use in potentially
explosive areas (see Explosion protection identification [810]). In explosion hazard areas,
only use approved explosion-proof electrical devices.
2.4 PROCESSIBLE WORKING MATERIALS
– Types of powder which can be charged electrostatically
– Metallic powder
Info
Contact your local WAGNER dealer and the lacquer manufacturer if you encounter
application problems.
2.5 MISUSE
Misuse can lead to physical injury and/or property damage! Special attention must be paid
that:
4 No liquid coating products, e.g., solvents or water-based lacquers, are processed.
4 No food, medicine or cosmetics are processed.
