6 Assembly and commissioning
22 Order number 2467031 | Edition 04/2024
P_06015
1
2
B A
B
A
3. Swing base plate/vibrator table in the direction of the arrow.
4. Screw in and tighten Allen screws (1) on both sides of the mobile base (Detail A).
5. Tighten the hexagon screws (2) on both sides of the mobile base (Detail B).
