3.3 Operation menu
① ②
③
④
⑤
⑥
⑦ ⑧ ⑨
⑩
Fig. 8 Interface of the WAREMA climatronic WebControl, Operation menu
Selection of rooms
Selection of channels, groups and scenes
Slider for changing the inclination angle of slat products
(e.g. external venetian blinds)
The grey degrees value indicates a possible inclination angle of the
sun shading product.
Slider for changing the position of sun shading products
The white percentage value indicates the new setpoint position of the
sun shading product
Up button moves the sun shading product upwards/inwards
Stop button stops the movement
Down button moves the sun shading product downwards/outwards
Start button moves the sun shading product after the position is
changed using one of the sliders.
