2011980_d•en•2015-12-01
We reserve the right to make technical changes
30
WAREMA climatronic® WebControl
Technical data
11 Technical data
WAREMA climatronic® WebControl Min. Typ. Max. Unit
Supply (terminal x2)
Operating voltage (SELV) 20 24 28 V DC
Current 40 mA
Enclosure
WAREMA climatronic WebControl
(L×W×H in mm)
95 × 54 × 60
(see Fig. 28)
Degree of protection IP30
Safety class III
Connection
controlbus (terminal x1) Spring terminals 0.6...0.8 mm ∅
controlbus line length 200 m
Ethernet RJ45 plug-in connector
Ethernet transfer rate 10/100 Mbit/s
Miscellaneous
Software class A
Location of use Clean ambient conditions
Conformity
available at www.warema.com
Ambient conditions
Operating temperature 0 20 40 °C
Storage temperature 0 20 50 °C
Rel. humidity
(not condensing)
10 40 85 %F
rel
Article numbers
WAREMA climatronic WebControl REG 2006 861
WAREMA Renkhoff SE
Hans-Wilhelm-Renkhoff-Strasse 2
97828 Marktheidenfeld
60 mm
95 mm
90 mm
54 mm
3 TE
Fig. 27 Dimensions
