WatchBot Home Security Camera - Camera Diagram

6
WatchBot Home Security Camera - User Guide
DCPower
Wi-Fi Antenna
LEDs
I/O Connector
LightSensor
Lens(turntofocus)
Microphone
MiniJackforSpeaker
Pan/Tiltmoon
RJ45NetworkPort
Warning: Do not forcibly move the camera pan/lt moon manually. This is likely to result in
damage to internal components and will void your warranty.
