3-8 Maintenance
13. Use a T27 TORX driver to remove the two screws securing the pump
head assembly to the support plate, and then remove the support plate.
Removing the pump head assembly
Caution: When you are placing the head assembly on a flat surface,
take care not to damage the cable that protrudes from the
transducer face.
Remove the screws that secure the
pump head assembly to the support
plate.
Remove the support plate.
