10.2.9. Changing the hydraulic oil lter
Shuto󰀨themachineasdescribedinsection5.8.
Open the hoods as described in section 10.2.1.
Open the cap (1).
Slowlypullthehydraulicoillter(2)withthe
protective cage (3) out of the enclosure (4).
Pullthehydraulicoillter(2)outoftheprotective
cage (3).
Slide the protective cage (3) back into the
enclosure (4).
Insertanewhydraulicoillter(2)intothe
protective cage (3) housed in the enclosure (4).
Pushthehydraulicoillter(2)allthewaydown.
Fill the hydraulic oil tank through the hydraulic
oillteruntilthelllevelindicatorintheview
glassshowsapprox.¾.Refertothetable
included in section 10.3 for the relevant
specicationsofthehydraulicoil.
Close the cap (1).
ATTENTION
Properlydisposeoftheusedhydrauliclter
in accordance with environmental protection
regulations.
Risk of environmental damage.
