10.2.10. Changing the hydraulic oil
Shuto󰀨themachineasdescribedinsection5.8.
Open the hoods as described in section 10.2.1.
Secure the articulated joint as described
in section 10.2.2.
Open the hydraulic oil drain (1) and allow the
hydraulic oil to drain into the collection vessel.
Place a suitable collection vessel under
the hydraulic oil drain (1).
Openthecap(2)andllhydraulicoilinto
the tank as described in section 10.2.9.
Refer to the table included in section 10.3 for
thespecicationsofthehydraulicoil.
Topo󰀨hydraulicoiluntiltheviewglass(3)
showsalllevelofapprox.¾.
Risk of scalding due to hot hydraulic oil.
WARNING
Wear protective gloves.
Do not reach into draining oil.
