Weber mt MC 85 - Changing the Fan V-Belt

51
1
2
3
4
5
10.2.13. Changing the fan V-belt
Shuto󰀨themachineasdescribedinsection5.8.
Open the hoods as described in section 10.2.1.
Loosen the set screw (1) and the fastening
screw (2) of the alternator (3) and relieve the
fan V-belt (4).
Remove the protective cage (5) of the fan.
Replace the fan V-belt (4).
Install the protective cage (5) of the fan.
Tighten the fan V-belt as described
in section 10.2.12.
Danger of burn injuries at hot engine and its attachments.
CAUTION
Allow the combustion engine to cool down
su󰀩cientlybeforestartingwork.
