Weber mt MC 85 - Checking Fluid Levels

39
1
2
min. max.
3
10.2.3. Checking uid levels
Shuto󰀨themachineasdescribed
in section 5.8.
Open the hoods as described in
section 10.2.1.
Danger of material damage from improper
checkingoftheuidlevels.
To check the engine oil level, wait for
approx.2minutesafterswitchingo󰀨
the combustion engine.
Pullouttheoildipstick(1)andwipeito󰀨
with a suitable cloth.
Reinsert the dipstick (1) and pull it out again.
The oil level must range between the
two markings (2). If this is not the case,
proceed as described in section 10.2.4.
The fuel level can be checked through
the slightly transparent fuel tank.
If the fuel level is low, open the cap (3).
Topo󰀨thefuelfollowingthespecications
in the table included in section 10.3.
Onlychecktheuidlevelswhenatoperating
temperature and with the machine parked
horizontally.
ATTENTION
