Weber mt MC 85 - Changing the Exciter; Drive Oil

48
1
3
2
3
10.2.11. Changing the exciter / drive oil
Shuto󰀨themachineasdescribedinsection5.8.
Secure the articulated joint as described
in section 10.2.2.
Secure the machine to keep it from overturning.
Loosen the dirt scrapers (1) on either side of
the drum (2).
Unscrew all screws (3) on the drum (2).
Risk of injury if the loosened drum slips or
rolls away.
Remove loosened drums immediately.
Secure the drum to keep it from slipping
or rolling away.
Place a suitable collection vessel under
the oil drain plug (3).
Open the oil drain plug (3) and allow the oil in the
exciter / drive to drain into the collection vessel.
Close the oil drain plug (3) and install
the drum (2).
WARNING
Only drain oil from the exciter / drive when
at operating temperature.
Risk of scalding due to hot hydraulic oil.
WARNING
Wear protective gloves.
Do not reach into draining oil.
