Weber mt MC 85 - Lubrication Chart

52
1
2
3
4
4
10.2.14. Lubrication chart
Shuto󰀨themachineasdescribedinsection5.8.
Lubricate the individual positions of the machine
asspeciedinthetablebelow.Usegrease
thatcomplieswiththespecication“KP2K-20”
according to DIN 51502.
ATTENTION
Properly dispose of residual lubricants
and cleaning agents in accordance with
environmental protection regulations.
No. Lubricating point Quantity
1 Articulated joint (top + bottom) 2 strokes
2 Cylinder on the left 2 strokes
3 Cylinder on the right 2 strokes
4 Drum bearings 3 strokes
Risk of environmental damage.
