Weber mt MC 85 - Page 57

57
Part Units Designation
1 1 Diesel engine
2 1 Tandem gear pump
3 1 Control block driving / steering
3.1 1 Pressure relief valve
3.2 1 2/2-way valve
3.3 1 4/3-way valve
3.4 1 4/3-way valve
3.6 2 Lowering brake valve
3.7 1 Check valve
3.8 1 Check valve
3.9 1 Throttle Ø 1.8
3.10 1 Pressure relief valve
3.11 1 Deadweight tester 10 bar
4 1 Control block vibration system
4.1 1 Pressure relief valve
4.2 1 3/2-way valve
4.3 1 4/3-way valve
4.4 1 Check valve
5 1 Brake
6 2 Gerotor motor
7 1 Steering cylinder
8 1 Gear motor
9 1 Pressure reservoir
10 1 Combination radiator
11 1 Check valve
12 1 Returnlter
MP1 1 Test port steering
MP2 1 Test port rapid motion
MP3 1 Test port vibration
