WEG CFW-11 RB User Manual

2
General Information
2-4 | CFW-11 RB
Feedback
- voltage
- current
Pre-
Charge
Input
filter
Power
supply
PE
Flash
memory
module
MMF-03
Digital
inputs
(DI1 to DI6)
Electronics power supplies and
interface between power and control
USB
CSR
HMI
CC11RB
Control
board
with
CPU
32 bit
"RISC"
Analog outputs
(AO1 and AO2)
Digital outputs
DO1 (RL1) to
DO3 (RL3)
HMI (remote)
Accessories
I/O expansion
(Slot 1 - white)
Synchronism
transformer
Analog inputs
(AI1 to AI2)
Capac.
Bank
DC Link
Power
Control
DC+
DC-
Figure 2.1: CFW-11 RB block diagram
NOTE!
Additional itens are need for the assembly of the complete unit, such as output inverter, DC fuses in
the DC link bus bar connection, external pre-charge circuit and filter.
