Technical Specications
8
8-16 | CFW-11
8.6 NEMA 1 KITS
351.0 mm [13.82 in]
- Weight of the conduit kit for frame size B: 0.9/2.0 kg/lb
Figure 8.9 - Frame size B with Nema 1 kit KN1B-01
KN1C-01
- Weight of the conduit kit for frame size C: 0.9/2.0 kg/lb
448.1 [17.64]
Figure 8.10 - Frame size C with the conduit kit KN1C-01
