9
I/O
The P013 value is indicated in hexadecimal, where each bit of the number indicates the status of a digital output,
that is, if Bit0 is ”0”, DO1 is inactive; if Bit0 is ”1”, DO1 is active, and so on, up to DO4.
✓
NOTE!
Parameter P013 requires the user to know the conversion between binary and hexadecimal numerical
system.
P275 - DO1 Function
P276 - DO2 Function
P277 - DO3 Function
Micro Mini Drives | 9-21
