8
MOTOR CONTROL
P580 - Fire Mode Configuration
Range: 0 = Inactive
1 = Active
2 = Active / P134
3 = Reserved
4 = Active / General Disable
Properties: cfg
Description:
This parameter defines how the Fire Mode functionality will work in the frequency inverter.
Table 8.3: Options for the parameter P580
Option Description
0 Fire Mode function is inactive
1
Fire Mode function is active. When the DIx set to Fire Mode is opened, “A211” will be shown on the HMI and no
changes will be made to the speed reference or to the inverter control
2
Fire Mode function is active. When the DIx set to Fire Mode is opened, “A211” will be shown on the HMI and the Speed Reference
will be set automatically to maximum (P134) value. The motor will accelerate to this new reference
3 Reserved
4
Fire Mode function is active. When the DIx set to Fire Mode is opened, “A211” will be shown on the HMI and the pulses
in the output will be disabled. Motor will coast to stop
P582 - Fire Mode Auto-reset Adjustable
Range: 0 = Limited
1 = Unlimited
Properties: cfg
Description:
This parameter defines how the auto-reset functionality will work in Fire Mode when a critical fault occur (DC Link
Overvoltage (F022) and Overcurrent/Short-circuit (F070)).
Table 8.4: Options for the parameter P582
Option Description
0 Limited. Auto-reset works as defined in P340 parameter
1
Unlimited. The auto-reset happens after 1s of a critical failure detection regardless of the
value set in P340
8.1.8 Control Configuration
P397 - Control Config
Range: 0 to F (hexa)
Bit 0 = Slip Compens. Regen.
Bit 1 = Dead Time Comp.
Bit 2 = Is Stabilization
Bit 3 = P297 reduction in A050
Properties: cfg
Description:
The bits of parameter P397, as shown in Table 8.5 on page 8-17, enable a series of internal options to configure
the control of the induction motor, such as:
8-16 | Micro Mini Drives
