9
I/O
The indicated values are obtained after the offset action and the multiplication by the gain.
P241 - Potentiometer Signal Function
Range: 0 = Speed Ref.
1 to 6 = Not Used
7 = SoftPLC
8 = Application Function 1
9 = Application Function 2
10 = Application Function 3
11 = Application Function 4
12 = Application Function 5
13 = Application Function 6
14 = Application Function 7
15 = Application Function 8
16 to 17 = Not Used
Properties: cfg
Description:
This parameter defines the function of the potentiometer signal input.
P242 - Potentiometer Signal Gain
Range: 0.000 to 9.999
Description:
This parameter defines the gain of the potentiometer signal input.
P244 - Potentiometer Signal Offset
Range: -100.0 to 100.0 %
Description:
This parameter defines the offset of the potentiometer signal input.
P245 - Potentiometer and FI1 Filter
Range: 0.00 to 16.00 s
Description:
This parameter sets the filter time constant of the potentiometer signal (when the accessory is connected) and of
the frequency input. It attenuates sudden changes in its value.
9.4 ANALOG OUTPUTS
The analog output (AOx) is configured by means of three types of parameters: Function, Gain and Signal, according
to the block diagram in Figure 9.4 on page 9-7.
The quantity of analog outputs depends on the expansion accessory IO’s. For further details, refer to the installation,
configuration and operation guide of the IO’s expansion accessory used.
9-6 | Micro Mini Drives
