COMMUNICATION
P754 - Profibus Baud Rate
Range: 0 = 9.6 kbit/s
1 = 19.2 kbit/s
2 = 93.75 kbit/s
3 = 187.5 kbit/s
4 = 500 kbit/s
5 = Not Detected
6 = 1500 kbit/s
7 = 3000 kbit/s
8 = 6000 kbit/s
9 = 12000 kbit/s
10 = Reserved
11 = 45.45 kbit/s
Description:
Parameters for configuration and operation of the Profibus interface. For a detailed description, refer to the
CANopen communication or DeviceNet communication manual available for download on the website:
www.weg.net.
12.6 ETHERNET
See below the parameters to configure and operate the Ethernet interface.
P850 - IP Address Config
Range: 0 = Parameters
1 = DHCP
Properties: cfg
P851 - IP Address 1
P852 - IP Address 2
P853 - IP Address 3
P854 - IP Address 4
Range: 0 to 255
Properties: cfg
P855 - CIDR Sub-net
Range: 1 to 31
Properties: cfg
P856 - Gateway 1
P857 - Gateway 2
