5
HMI
P210 - Ref. Decimal Point
P511 - SoftPLC Indication Form
Range: 0 = wxyz
1 = wxy.z
2 = wx.yz
3 = w.xyz
Description:
This parameter allows setting the position of the decimal point displayed on the HMI. P210 is linked to the indication
of parameters P001 and P002. P511 is is linked to the indication of the SoftPLC user’s parameters. That is, any
SoftPLC user’s parameter linked to the SoftPLC indication form will be displayed in this format.
P213 - Bar Scale Factor
Range: 1 to 9999
Description:
This parameter configures the full scale (100 %) of the bar graph to indicate the parameter selected by P207.
P842 - Quick View 1 IR
P843 - Quick View 2 IR
Range: 0 to 959
Description:
These parameters define which parameters (their respective values) will be viewed by using the key of the infrared
remote control (available with expansion module).
For further details, refer to the installation, configuration and operation guide of the expansion module.
5-4 | Micro Mini Drives
