WEG CFW100 - Page 78

8
MOTOR CONTROL
Table 8.6: Characteristics of IV pole WEG standard motors (indicative values)
Power
(HP) (kW)
Frame
Size
Voltage
[P400]
(V)
Current
[P401]
(A)
Frequency
[P403]
(Hz)
Speed
[P402]
(rpm)
Efficiency
[P399]
(%)
Power
Factor
Stator
Resistance [P409]
(Ω)
0.16 0.12 63
220
0.85
60
1720 56.0 0.66 21.77
0.25 0.18 63 1.12 1720 64.0 0.66 14.87
0.33 0.25 63 1.42 1720 67.0 0.69 10.63
0.5 0.37 71 2.07 1720 68.0 0.69 7.37
0.75 0.55 71 2.90 1720 71.0 0.70 3.97
1.00 0.75 80 3,08 1730 78.0 0.82 4.13
1.50 1.10 80 4.78 1700 72.7 0.83 2.78
2.00 1.50 90S 6.47 1720 80.0 0.76 1.55
3.00 2.20 90L 8.57 1710 79.3 0.85 0.99
4.00 3.00 100L 11.6 1730 82.7 0.82 0.65
5.00 3.70 100L 13.8 1730 84.6 0.83 0.49
0,16 0,12 63 0,49 1720 56,0 0,66 65,30
0,25 0,18 63 0,65 1720 64,0 0,66 44,60
0,33 0,25 63 0,82 1720 67,0 0,69 31,90
0,5 0,37 71 1,20 1720 68,0 0,69 22,10
0,75 0,55 71 1,67 1720 71,0 0,70 11,90
1,00 0,75 80 1,78 1730 78,0 0,82 12,40
1,50 1,10 80 2,76 1700 72,7 0,83 8,35
2,00 1,50 90S 3,74 1720 80,0 0,76 4,65
3,00 2,20 90L 4,95 1710 79,3 0,85 2,97
4,00 3,00 100L 6,70 1730 82,7 0,82 1,96
5,00 3,70 100L 7,97 1730 84,6 0,83 1,47
6,00 4,50 112M 9,41 1730 84,2 0,86 1,15
7,50 5,50 112M 11,49 1740 88,5 0,82 0,82
10,0 7,50 132S
380
15,18
60
1760 89,0 0,84 0,68
0,16 0,12 63
230
0,73
50
1375 57,0 0,72 30,62
0,25 0,18 63 1,05 1360 58,0 0,74 20,31
0,33 0,25 71 1,4 1310 59,0 0,76 14,32
0,50 0,37 71 1,97 1320 62,0 0,76 7,27
0,75 0,55 80 2,48 1410 68,0 0,82 5,78
1,00 0,75 80 3,26 1395 72,0 0,81 4,28
1,50 1,10 90S 4,54 1420 77,0 0,79 2,58
2,00 1,50 90L 5,81 1410 79,0 0,82 1,69
3,00 2,20 100L 8,26 1410 81,5 0,82 0,98
4,00 3,00 100L 11,3 1400 82,6 0,81 0,58
5,00 3,70 112M 14,2 1440 85,0 0,83 0,43
0,16 0,12 63 0,42 1375 57,0 0,72 91,85
0,25 0,18 63 0,60 1360 58,0 0,74 60,94
0,33 0,25 71 0,80 1310 59,0 0,76 42,96
0,50 0,37 71 1,13 1320 62,0 0,76 21,81
0,75 0,55 80 1,42 1410 68,0 0,82 17,33
1,00 0,75 80 1,86 1395 72,0 0,81 12,85
1,50 1,10 90S 2,61 1420 77,0 0,79 7,73
2,00 1,50 90L 3,34 1410 79,0 0,82 5,06
3,00 2,20 100L 4,75 1410 81,5 0,82 2,95
4,00 3,00 100L 6,47 1400 82,6 0,81 1,75
5,00 3,70 112M 8,18 1440 85,0 0,83 1,29
7,50 5,50 132S 11,0 1450 86,0 0,84 0,76
10,0 7,50 132M
400
14,8
50
1455 87,0 0,84 0,61
✓
NOTE!
Read chapter 3 Installation and Connection of the frequency inverter user’s manual before installing,
energizing or operating the inverter.
Sequence for installation, verification, power up and start-up:
1. Install the inverter: according to chapter 3 Installation and Connection of the user’s manual, making all the
power and control connections.
2. Prepare and power up the inverter according to Section 3.2 Electrical Installation of the user’s manual.
Micro Mini Drives | 8-29
