General Information
4 800092-01 Rev. A www.wegener.com
C-Video Output Yellow RCA
Audio 1 and 2 (two analog audio ports)
Connector Input/Output Description
Right Audio Output Red RCA Unbalanced
Left Audio Output White RCA Unbalanced
S/PDIF Digital Audio
Connector Input/Output Description
1 Output Coax/Electrical
2 Output TosLink/Optical
HDMI Digital Audio/Video
Connector Input/Output Description
HDMI I/O Digital Audio/Video; HDCP Copy Protection;
Display Data Channel
USB
Connector Input/Output Description
1 I/O USB V2.0 Port
10/100 BaseT (RJ-49) Ethernet Auto Detect
Connector Pin Input/Output Description
1 Output TXD +
2 Output TXD -
3 Input RXD +
4 NA No Connection
5 NA No Connection
6 Input RXD -
7 NA No Connection
8 NA No Connection
RS-232 Serial Port Phone Jack
Connector Pin Input/Output Description
1 NA No Connection
2 Output RXDB Data
3 Input TXDB Data
4 NA No Connection
5 NA Ground
6 NA +5V DC
External Input/Output Interfaces
