Wegener iPump 562 - Composite Video Output; Component Video Output; Table 1.5: Ipump 562 Composite Video Output

www.wegener.com 800092-01 Rev. A 7
Unity 552 User’s Manual
Composite Video Output
Table 1.5: iPump 562 Composite Video Output
Component Video Output
All specs below are presumed for NTSC and PAL unless otherwise specified. Tested per
RS250C. Tested at max resolution with ~6 Mbps PES rate.
Supported Digital Video Resolutions SD:
480I / 29.97
480P / 59.94
576I / 25
576P / 50
Horizontal: 720, 704, 640, 544, 528, 480 and 352
HD:
1080I / 29.97
Horizontal: 1920, 1440, 1280, and 960
1080I / 25
Horizontal: 1920, 1440, 1280, and 960
720P / 50
Horizontal: 1280, 960, and 640
720P / 59.94
Horizontal: 1280, 960, and 640
Supported Color Space Sampling
Scheme
4:2:0 All Supported Formats
4:2:2 SD Formats
Composite Video Output
Line 21 Closed captioning Divicom and ATSC EIA-608-B
TELETEXT CCIR/ITU-R Broadcast Teletext System B
Output Level 1.0 Vp-p, < 5% Deviation
Output Impedance 75 Ohms
Multi-burst Frequency Response NTSC: From 0.5 to 4.2 MHz: < +0/-3 dB PAL: From 0.5
to 4.2 / 5.8 MHz: < +0/-3
Differential Gain < 3%
Differential Phase < 3 Degrees
Line Time W-form Distortion < 2% p-p
Field Time W-form Distortion < 2% p-p
Video Decoder
