Wegener iPump 562 - Rear Panel Connections; External Input;Output Interfaces; Table 1.1: Ipump 562 Interconnect Descriptions; Table 1.2: Ipump 562 External Input;Output Interfaces

www.wegener.com 800092-01 Rev. A 3
Unity 552 User’s Manual
Rear Panel
Connections
The iPump 562 rear panel provides following connections:
Table 1.1: iPump 562 Interconnect Descriptions
External
Input/Output
Interfaces
The details on each of the interfaces are described below:
Table 1.2: iPump 562 External Input/Output Interfaces
Port / Signal Connector Type Description
DC IN M Power Jack +12 V DC 5 A
RF Switch IN - Port 1 F 950 to 2150 MHz signal accepted; Universal/Std
Pwr
RF Switch IN - Port 2, 3, 4 F 950 to 2150 MHz signal accepted; No LNB power
RS-232 Port RJ-12 Serial Asynchronous for terminal, printer or Aux
Data
Audio OUT 1 (R&L) 2 RCA Phone Jacks Audio stereo
Audio OUT 2 (R&L) 2 RCA Phone Jacks Audio stereo
Composite Video RCS Phone Jack Composite Video Monitor NTSC or PAL at 1 Vp-p
C-Video RCS Phone Jack C-Video NTSC or PAL at 1 Vp-p
Component Video 3 RCS Phone Jacks Component HD/SD Video YPbPr
HDMI Type A receptable High Definition Multimedia Interface (Digital A/V)
S/PDIF RCA Phono Jack S/PDIF Coax Digital Audio
S/PDIF Optical TosLink S/PDIF Fiber Digital Audio
ETHERNET RJ-45 ETHERNET 10/100 BaseT
USB USB USB V2.0 port
External Input/Output Interfaces
RF
Connector Input/Output Description
4 RF Inputs from LNB Port 1 I/O; Port 2-4 Input Port 1 Universal/ Standard LNB Port 2-4 No
LNB Voltage
Component Video
Connector Input/Output Description
Component Y Output Green RCA
Component Pb Output Blue RCA
Component Pr Output Red RCA
Composite Video
Connector Input/Output Description
Composite Video MON Output Yellow RCA
