Operation
26 800092-01 Rev. A www.wegener.com
Set LAN-based Decode options
Use following steps to display Decoder Source screen on the OSD menu:
1. Navigate to the Decoder Setup screen
2. Press the up or down arrow buttons to select Decoder Source.
3. Press Enter.
4. Press the up or down arrow buttons to select either LAN-Multicast or LAN-Unicast.
5. Press Enter.
6. Select Activate Settings.
7. Press Enter.
Figure 3.15: iPump 562 OSD Decoder Source
Use the Decoder Source screen to set and display the LAN Decode options.
Table 3.9: LAN Decode Options
Set LAN IP Networking options
Use following steps to display LAN IP Setup screen on the OSD menu:
1. Navigate to the Unit Setup screen, see Unit Setup screen on page 23.
2. Press the down arrow button to select LAN IP Setup.
3. View the details as shown in Figure 3.16.
Option Possible values
IP-Address Multicast or Unicast IP Address
IP-Port Number The corresponding IP Port number
Audio Routing Stereo or Left/Right on both
Audio Attenuation 0 through 20
S/PDIF Mode Passthru, Linear PCM or Off
