www.wegener.com 800092-01 Rev. A 9
Unity 552 User’s Manual
Serial Port
Table 1.10: iPump 562 Serial Port
Local Hard Disk Driver (HDD)
Table 1.11: iPump 562 HDD
LNB DC Power (RF Port 1 ONLY)
Universal and Standard LNB Supported. See Astra PTS403d.
Table 1.12: iPump 562 LNB DC Power (RF Port 1 ONLY)
AC Power
Table 1.13: iPump 562 AC Power
Serial Port
RS-232 RJ11
Selectable services Auxiliary character-based async output E-mail
character-based async output Terminal monitoring and
control
Baud Rates 2400 to 115200 baud
Formatting 8 data-bits, one start, one stop-bit, half-duplex, no parity
Local Hard Disk Driver (HDD)
Storage Capacity 8 GB
Interface IDE
LNB DC Power (RF Port 1 ONLY)
Voltage Standard: 18VDC Universal: 13 or 18 VDC, for LNB
polarity selection
22 KHz tone 22 kHZ control tone, for LNB DRO baud selection,
Universal mode
Current 350 mA max
Short-circuit protection Thermal Fuse and Foldback Regulator
AC Power
Voltage External 100-240 auto-detect/selected
Frequency 50 or 60 Hz +/-2%
Power consumption 30 watts with full LNB DC load
