Wegener iPump 562 - Video Decoder; Table 1.4: Ipump 562 Video Decoder

General Information
6 800092-01 Rev. A www.wegener.com
Video Decoder
Table 1.4: iPump 562 Video Decoder
Aggregate MPEG Transport Rate 8PSK = 80.346; S1 QPSK = TBD 2.5 to 48.38 Mbps (limited
by max symbol-rate and inner FEC chosen), defined for
188-byte MPEG transport packets
Max/Min Eb/No @ Video Threshold S1QPSK:
FEC: Eb/No (dB)
1/2: 4.5
2/3: 5.0
3/4: 5.5
5/6: 6.0
7/8: 6.4
S2QPSK:
FEC: Eb/No (dB)
1/2: 1.5
3/5: 2.0
2/3: 2.4
3/4: 2.8
4/5: 3.2
5/6: 3.5
8/9: 4.2
9/10: 4.4
S28PSK:
FEC: Eb/No (dB)
3/5: 3.5
2/3: 4.1
3/4: 4.9
5/6: 5.9
8/9: 6.9
9/10: 7.2
Video Decoder
Compression System MPEG-2/MPEG-4 and H.264 - Standard and High
Definition
Analog (Composite) Output Formats NTSC or PAL
RF Characteristics
