Weinmann VENTIlogic BiLevel ST User Manual

Overview 3
EN
1 Bacteria filter
For protecting patient from bacteria, especially if
the device is being used by several patients.
2 Connec ting cord
For connecting the VENTI logic to the supply.
3 Handle
For transporting the unit.
4 Serial interfaces
These are used to connect devices for displaying
and analysing therapy data.
5 Control panel and display
For controlling and monitoring the VENTI logic
and connected accessories.
6 Connection for humidifier
For connecting the VENTI click humidifier availa -
ble as an accessory.
7 Unit outlet
Respiratory air flows out from here to the patient
via the hose system and mask.
8 Sealing plug (2x)
For sealing the pressure measuring hose during
cleaning.
9 Drying adapter
Required if the hose system is being dried with the
VENTI logic .
10 Adapter
For connecting the hose system to the unit outlet.
11 Pressure measuring hose
For measuring the pressure in the mask and thus
for controlling flow.
12 Hose system
The air flows to the mask through the hose system.
The hose system consists of corrugated hose,
pressure measurement tube and adapter.
13 Exhalation system
Carbon dioxide-enriched expired air escapes
here during therapy.
14 Mask
Respiratory air at the necessary therapy pressure
is administered to the patient via the mask.
15 Headgear
For correct and secure positioning of the mask.
16 Filter compartment cover, air inlet
For covering and securely positioning the coarse
and fine dust filter.
17 Supply connection
This is where the connecting cord is attached to
the unit.
18 Cable securing clip
Prevents the unit being disconnected inadvertently
from the power supply.
19 Battery connection VENTI power
For connecting the VENTIpower mobile power
supply available as an accessory.
20 O
2
connection VENTI-O
2
For connecting the VENTI-O
2
oxygen connection
valve available as an accessory.
21 Alarm acknowledgement switch with LED
The alarm acknowledgement switch can be used
for temporary muting of alarms. The LED gives a
visual indication of alarms.
22 On/off switch
For switching the VENTIlogic on and off.
23 Dial
Central control for the VENTIlogic, for navigating
in the menu.
24 Operating switches
For rapid setting by a doctor, locked out in
patient mode.
