42
SWPR Menu Reference
Scan Lists – Press SEL to assign the object to scan
lists. An asterisk (*) indicates an assigned scan list.
Type – All Bands or Public Safety. Public Safety
activates Sub-bands.
Sub-bands – Press Sel to toggle active Public Safety
sub-bands. An asterisk (*) indicates an active sub-band.
Tag – The display name for the object.
L/Out – Permanent lockout status for the object.
LED Mode – Solid or Flash.
LED Color – 0=Off, 1=Red, 2=Yellow, 3=Green,
4=Cyan, 5=Blue, 6=Magenta, 7=White.
Latch LED – Off, the Alert LED is on only during a
transmission; On, the Alert LED remains lit after a
transmission, unless overridden.
Backlight – On, Off, or Flash.
Alarm – None, Chirp, Hi-Lo, Alert, Ring, 2-Chirp,
Fast Hi-Lo, DTMF#.
Fav – Assigns the object to the Favorites scan list.
Atten – Attenuation. On or Off.
Delay – On or Off.
Delay Time – (1-250) Delay time in 100 ms.
Zeromatic – On or off.
Special – On or Off. Sweeps the RF spectrum in 1
MHz increments. If the sweep finds activity SWPR
sweeps that range to find the source.
Search Dir – Up or Down.
Hit Count – Number of received transmissions for
the object. Global Hit Counts must be set to on.
Press the Dflt softkey to reset to 0.
