pl Załącznik
206 WILO SE 2018-12
Holding register
(Protocol)
Name Data type Scale & unit Elements Access Added
40043
(42)
Pump 3 mode ENUM 0. Off
1. Hand
2. Auto
RW 31.000
40062
(61)
Switch box state BITMAP 0: SBM
1: SSM
R 31.000
40139 - 40140
(138-139)
Error state BITMAP32 0: Sensor error
1: P man
2: P min
3: FC
4: TLS
5: Pump 1 Alarm
6: Pump 2 Alarm
7: Pump 3 Alarm
8: Pump 4 Alarm
9: Pump 5 Alarm
10: Pump 6
Alarm
11: -
12: -
13: Frost
14: Battery Low
15: High water
16: Priority off
17: Redundancy
18: Plausibility
19: Slave com-
munication
20: Net supply
21: Leakage
R 31.000
40141
(140)
Acknowledge BOOL W 31.000
40142
(141)
Alarm history index UINT16 RW 31.000
40143
(142)
Alarm history error
code
UINT16 0.1 R 31.000
40198
(197)
State float swiches BITMAP 0: DR
1: Ps off
2: P1 on
3: P2 on
4: HW
R 31.102
40204
(203)
Set points water le-
vel 1
UNIT16 1 cm RW 31.102
40205
(204)
Set points water le-
vel 2
UNIT16 1 cm RW 31.102
40206
(205)
Set points water le-
vel 3
UNIT16 1 cm RW 31.102
40212
(211)
Set points water le-
vel 1
UNIT16 1 cm RW 31.102
40213
(212)
Set points water le-
vel 2
UNIT16 1 cm RW 31.102
40214
(213)
Set points water le-
vel 3
UNIT16 1 cm RW 31.102
40220
(219)
Dry run level UNIT16 1 cm RW 31.102
40222
(221)
High water level UNIT16 1 cm RW 31.102
