Manual 26815 QuickTrip Electro-Hydraulic Trip Block Assembly
Woodward 60
Table A-1. Installation and Commissioning Checklist (Continued)
Category
Parameter
Specification
This Installation
Discrete
Outputs
Wiring: Trip #1 NO TB2, Terminal 7
Wiring: Trip #1 COM TB2, Terminal 8
Wiring: Trip #2 NO TB2, Terminal 9
Wiring: Trip #2 COM TB2, Terminal 10
Terminal Torque
0.2-0.25 Nm
(1.75-2.25 in-lbf)
Breakers
Breakers used between
logic solver NO and
QuickTrip
Wiring: Run #1 NO TB2, Terminal 11
Wiring: Run #1 COM TB2, Terminal 12
Wiring: Run #2 NO TB2, Terminal 13
Wiring : Run #2 COM TB2, Terminal 14
Terminal Torque
0.2-0.25 Nm
(1.75-2.25 in-lbf)
Breakers
Breakers used between
logic solver NO and
QuickTrip
Connector Flange Screw
Torque
0.5 Nm (4.4 in-lbf)
Electronics
Module
Power Supply #1 LED
Indicator
ON
Power Supply #2 LED
Indicator
ON
(only if PS#2 is used)
Run LED Indicator (green)
ON when valve in run
(closed) state
Trip LED Indicator (red)
ON when valve in trip
(open) state
Top cover Torque
136-190 Nm
(100-140 ft-lbf)
Top Cover
Retaining
Clip
Screws
Torque
2-2.7 Nm
(18-25 in-lbf)
Actuation
Times
Trip Time < 50 ms
Actuation (close) Time < 1 s
Proof Test Operation of Proof Test
Initiate proof test and
ensure correct operation of
all three QuickTrip modules
Released
