Operation pH/Cond 3320
22 ba77054e03 03/2018
4.5 Channel display
The pH/Cond 3320 manages the connected sensors and displays which
sensor is plugged to which connection.
4.5.1 Display of several sensors in the measuring mode
The measured values of the connected sensors can be displayed in the follow-
ing ways:
 Clear display of all connected sensors
 Detailed display of one sensor
With the softkey you can very easily switch between the two display types. The
suitable softkey is displayed depending on the operating situation.
Channel display
Display of the plug position
for the respective parameter
The filled bar indicates for
each connected sensor to
which plug position of the
meter it is connected.
pH
6.949
24.8 °C
15.02.2014
14:15
USB output
pH 6.966
25.0 °C
ϰ 0.470 1/cm
25.0 °C
15.02.2014
14:15
USB output
pH
6.966
25.0 °C
15.02.2014
14:15
USB output
