Programming Scan Groups Using the Front Panel
Although Wulfsberg highly recommends using the PC based FCT software to program scan groups for
the C-5000P, they can also be programmed from the front panel. The process is as follows.
 Ensure you are on the HOME PAGE.
 Press the PROG button. If the C-5000P has been programmed to require a password to enter
this mode, you will be prompted to enter a password, as follows.
E N T E
R
P
A
S
S
W
O
R
D
2
# = . .
.
.
<
E
N
T
E
R
>
 Input the appropriate password using the keypad and press the ENTER button.
 Press the MODE button until the following display page appears.
P
R
O G : 2
=
N
E
X
T
3
=
B
A C K
< E N T E
R
>
=
S
C
AN
G
R
O
U P S
 Press the ENTER button to invoke the SCAN GROUP MAIN MENU PAGE, depicted below.
P
R
O G : S
C
AN
G
R
O
U
P
2 = A D D
3
=
C
H
G
4
=
D
E L
 Press the MODE button to add a new scan group or the EDIT button to modify an existing scan
group. The pages are nearly identical for both functions. The illustrations that follow assume we
are adding a scan group, i.e. we pressed the MODE button.
P
R
O G : 2
=
N
E
X
T
3
=
B
A C K
A D D - 0 9
.
.
.
.
.
.
.
.
 Use the cursor/value knobs to select the number for the new scan group. Only unused scan
group numbers will be displayed. Press the MODE button to go to the next menu page.
The C-5000P must be configured before preset scan groups
are programmed, or the unit will not operate properly.
