Ci7XX0 BENCHTOP SPECTROPHOTOMETER
48
4. Insert Instrument into box
a. Lower instrument into box.
i. Hold instrument by front and rear grips.
ii. Lift and lower instrument into box oriented in foam as shown.
b. Wrap bag around instrument.
c. Place the top instrument foam piece on top of instrument and position the foam to the
instrument as shown.
Shown without
bag for clarity
Door forward
Lock button “UP”
Front of
instrument
Front of
instrument
Small foam
block
