Model A40
Stator Size 136 x 24mm
KV Value 75RPM/V
Maximum Tension (Single Motor) 42kg
Rated Power (Single Motor) 3000W
Motor
Model VC13180
Maximum Continuous Operating Current 80A
Maximum Operating Voltage 56.6V
Electronic Speed Controller
Model P4718
Diameter × Screw Pitch 47 x 18inch
Foldable Propeller
Rated Voltage DC50V
Operating Voltage DC25V-55V
Rated Torque 150Kg·cm@50V
Rated Current 0.5A@50V
No Load Speed 400°/second
Tilt Servo
Propulsion System
