XAG V40 - GNSS XRTK4 Mobile Station Specifications

XAG AUSTRALIA

RTK Positioning Module for Agricultural Use
Model XRTK4
Dimensions (Diameter x Height)
154mm x 83.6mm (RTK Module)
154mm x 1230mm (RTK Module + Rod)
Weight 1.5 Kg (RTK Module)
Port/Panel
Button × 3, Positioning Indicator × 1
Networking Indicator × 1,
Power Indicator × 1
IP Rating IP65
Operating Temperature -20° - 50° C
Storage Temperature -40° - 85° C
Relative Humidity 100%, condensation
Warranty Details 12 Months
GNSS Performance & Specifications
Compatible motherboard K726
GNSS Frequency
BDS
GPS
GLONASS
Galileo
QZSS
B1I / B2I / B3I / B1C / B2a
L1 / L2 / L5
L1, L2, L2C,
E1 / E5a / E5b
L1 / L2 / L5
RTK Positioning Accuracy
Horizontal ±10mm+1ppm (RMS)
Vertical ±15mm+1ppm (RMS)
Initialization time 
Initialization Reliability >99.9%
Data update rate
Maximum 20 Hz (Raw data)
Maximum 20 Hz (Positioning data)
GNSS XRTK4 Mobile Station
