Xantrex Freedom X 2000 User Manual

System Specifications
975-0822-01-01 75
System Specifications
Freedom X 2000 - 230V
Transfer relay rating (A
a
)
30AV
Transfer time (ms
b
)
Shore to inverter:
Inverter to shore:
<20ms
<20ms with a 20-s delay
Transfer voltage (V)
Shore to inverter:
Inverter to shore:
<180V Vand>280V V
<270V Vand>190V V
Cooling
Fan, activated by any of the
following:
High internal temperature
High AC output power
Over Voltage Category [OVC]
Input AC: OVC II
Output AC: OVC II
Safety Protective Class Class I
Table 16System specifications
a
Circuit breakers shall not carry more than 80% of their current rating continuously.
b
To change the AC Transfer time (mode), see Adjusting Settings in Configuration Mode on page 47.
Freedom X 2000 - 230V
Operating voltage range
10–17.0 V Z
Maximum non-operating voltage
25.2 V Z
Nominal voltage
12.0 V Z
Nominal current at full load
192 A Z
Table 17 DC input for inverting
Freedom X 2000 - 230V
Output voltage options
220, 230, 240VV
Continuous power
a
2000W @ 40 °C
Continuous current
8.3AV
Surge power (5 s) 4000W
Frequency
b
50 (or 60) Hz
Wave shape True Sine Wave
Peak efficiency 91%
Full load efficiency
≥87.5%
Table 18 AC output for inverting
a
Power derates to 85% when output voltage is set to 220VV.
b
To set the AC Frequency, see Adjusting Settings in Configuration Mode on page 47.

Xantrex Freedom X 2000 Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Frequency	60 Hz
Efficiency	90%
Waveform	Pure Sine Wave
Protections	Overload, Over Temperature, Short Circuit
