4 Freedom XC Owner's Guide
Over temperature
Alarm and
Shutdown
During Battery Mode, the Freedom XC
automatically alerts you if it is overheating
and approaching the over-temperature
shutdown limit. The Freedom XC
automatically shuts down when the limit is
exceeded. See Troubleshooting Reference on
page 76 for precautions.
Built-in Charge
Formulas
For the inverter/charger to perform at the
highest level, the batteries must be charged
correctly. The Freedom XC has optimized
algorithms for flooded, gel, AGM, custom,
and lithium iron phosphate [LFP (or LiFePO
4
)]
batteries.
Manual
Equalization
Over a period of time, the cells in a flooded
battery can develop uneven chemical states.
This can result in a weak (undercharged) cell
which, in turn, can reduce the overall capacity
of the battery. To improve the life and
performance of a non-sealed, flooded battery,
the Freedom XC multi-stage charging cycle
includes a manual equalize mode that can be
used, if recommended by the battery
manufacturer.
Dead Battery
Charging
Another feature of the Freedom XC is dead
battery charging. This is the ability to
recharge batteries, even if the battery voltage
has reached 0VDC.
Ignition Control The Freedom XC provides two user-
selectable options for ignition control:
n Ignition Auto-on: The Freedom XC
can automatically turn the
inverter/charger on and off in tandem
with the vehicle's ignition circuit or a
manually operated remote switch.
n Ignition Lockout: The Freedom XC
features the ability to inhibit the
inverter/charger from operating in the
absence of a voltage signal from a
vehicle's ignition circuit. This is
particularly useful if the inverter/charger
is required to operate only when a
vehicle's engine is running.
Configurable AC
Output Frequency
and Voltage
The Freedom XC is factory set to 60Hz AC
output frequency and 120V AC output
voltage. It can be configured to 50Hz for use
in regions outside the USA and Canada. The
AC voltage setting can also be configured to
either of three settings: 108, 110, or 120volts.

Xantrex Freedom XC 2000 Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Frequency	60 Hz
Waveform	Pure Sine Wave
Efficiency	90%
Operating Temperature	-4°F to 140°F (-20°C to 60°C)
Transfer Time	20ms
