Basic Installation Procedures
975-0784-01-01 21
Inverter/charger
Cable Length:
Battery to
Inverter (one
way)
Minimum
Cable
Size
Maximum
battery
Fuse Size
Freedom XC
1000
Less than 5 feet
(1.5 meters)
No. 2 AWG 150 ADC
Freedom XC
2000
No. 2/0
AWG
250 ADC
NOTE:It is not recommended using a cable longer than 5 feet
(1.5 meters) in each direction. North American cable sizes above
are based on the US National Electrical Code Table 310.17 -
75°C cables, assuming an ambient temperature of 30 °C cables.
Table 6Required Cable Sizes
IMPORTANT: Using the correct cable size is critical to achieving
the rated performance of the Freedom XC unit. When starting a
heavy load the Freedom XC can draw current surges from the
battery of up to 400A. If the DC wiring is too small the voltage drop
from this surge will result in a voltage at the Freedom XC
terminals that is too low for the Freedom XC to operate correctly.
The Freedom XC may appear to operate correctly with smaller
cables until a heavy load such as a microwave or refrigerator
attempts to start - then the unit may work correctly sometimes
and not work correctly other times.
DC Disconnects and Over-Current Devices
The DC circuit from the battery to the Freedom XC must be
equipped with a disconnect and over-current device. This usually
consists of a circuit breaker, a “fused-disconnect, or a separate
fuse and DC disconnect. Do not confuse AC circuit breakers
with DC circuit breakers. They are not interchangeable. The
rating of the fuse or breaker must be matched to the size of cables
used in accordance with the applicable installation codes. The
breaker or disconnect and fuse should be located as close as
possible to the battery, in the positive cable. Applicable codes
may limit how far the protection can be from the battery.
Batteries
The Freedom XC uses 12-volt battery banks. Every Freedom XC
system is recommended to have a deep-cycle battery (house) or
group of batteries with a total capacity of 100Ah or more which
provides the DC current that the Freedom XC converts to AC.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xantrex Freedom XC 2000 and is the answer not in the manual?

Xantrex Freedom XC 2000 Specifications

General IconGeneral
Continuous Power2000W
Surge Power4000W
Input Voltage12V DC
Output Voltage120V AC
Output Frequency60 Hz
WaveformPure Sine Wave
Efficiency90%
Operating Temperature-4°F to 140°F (-20°C to 60°C)
Transfer Time20ms
