E lectrica l
Req uirements
B-5
Technical Sp ecifications
Electrical Requirem ents
Env ironm en tal Req uirem ents
Power
Requirements
3825 3225/2025
110 V model 88-132 VAC; 50/60 +/-3 Hz 99-122 VAC; 59.4 to 60.6 Hz
220 V model 187-264 VAC; 50 +/-3 Hz 198-242 VAC; 49.5 to 50.5 Hz
Power
Consumption
(full system)
110 V model 1400 W, 12A 1200 W, 10A
220 V model 1400 W, 7A 1150 W, 5A
Noise Level Idle maximum: 45 dB (A)
Printing maximum:
3825 — 57 dB(A)
3225 — 55 dB(A)
2025 — 55 dB(A)
» N ote: Me asured at a heigh t of 1.5
m eters an d a distance of 1 m eter from
all fou r sides of th e printer .
Ozone Density The printer emits less than 0.1 parts per million
(ppm) of ozone maximum with a 100% duty cycle for
8 hours of continuous operation.
Relative Humidity Printing: 20-80% RH (non-condensing)
Storage: 15-95% RH (non-condensing)
Temperature Range Printing: 50° to 90° F (10° to 32° C)
Storage: -4° to 109° F (-20° to 43° C)
